2d /3d/4d Medical Ultrasound Machine

Place of Origin : Guangdong, China

Brand Name : MSL

Model Number : MSLCU62

Language : Japanese, German, Spanish, Italian

Power Source : Electric

Warranty : 2 years

Type : CONVEX

Display Type : 10.1inch tft lcd

After-sale Service : Online technical support

Application : GI, MSK, POC, OB, Cardiac, Gynecology

Shelf Life : 1years

display mode : color

Quality Certification : ce

Instrument classification : Class II

probe : convex probe

Product name : ultrasound machine

Display mode : B/2B/4B/M/B+M

Display : 12.1 inch LED Screen

Ports : 2 USB ports

Indicators : Power/Battery/Standby/HDD status

Image storage : 8-TGC assuring accurate image control

Feature : 100% Guaranteed

GW : 11KG

Function : obstetrics, gynecology, pediatrics, etc

Packing : 525mm*420mm*505mm

Contact Now

Product Description

Diagnostic confidence and wide clinical applications . Full digital technology . IP (image process) for fast image optimization . 8-TGC assuring accurate image control . A broad range of transducers for obstetrics, gynecology, abdomen, urology, small parts, orthopedics and pediatrics applications Improve efficiency by optimizing the workflow . Fast boot-up within 20s . User-defined keys to define personalized operations . One key images or cines saved to local disk or USB

Specification

2d /3d/4d medical ultrasound machine		MSLPU09
Standard Configuration: . 12.1-inch LED monitor . One transducer connector . Control Panel . Handle . Indicators: Power/Battery/Standby/HDD status . I/O Interfaces . 2 USB ports . 1 VGA OUT port . 1 Video OUT . 1 S-Video OUT . Measurement & Calculation software packages	Optional: . Second transducer connector . DICOM 3.0: Image storage and printing . Footswitch . Mobile trolley: UMT-110 . Carrying Case . Keyboard dust-proof cover . Needle-guided brackets
		Probe ≤3（80＜depth≤130)	80 elements R60
		Scanning depth	≥160mm
		Lateral resolution mm	≤3（depth≤80）≤4（8＜depth≤130）
		Axial resolution mm	≤2（depth≤80 ≤3（80＜depth≤130)
		Blind zone mm	≤5
		Horizontal geometric position accuracy	≤15
		Longitudinal geometric position accuracy %	≤10
		Probe slice thickness index mm%	≤10
		Perimeter and area measurement deviations %	±20
		M-mode time and distance deviation	±10
		N.W	5KG
		G.W	10KG
		Package Size	47.022.040.0CM
